Sandpiper S30 Non-Metallic 3" (80 mm) Standard Duty AODD Pump

Sandpiper S30 Non-Metallic 3" (80 mm) Standard Duty AODD Pump

Brand: Sandpiper

Category: Diaphragm Pumps (AODD Pump), Standard Duty Ball Valve Pump

Quantity: In Stock

non-metallic aodd pump

3 inch aodd pump

standard duty ball valve pump

3 inch non-metallic air-operated double diaphragm pump

WR10 ⅜" (10 mm) Non-Metallic – Standard Duty Non-Metallic Poppet Valve

Sandpiper S20 Non-Metallic 2" (50 mm) AODD – Standard Duty AODD Pump

Description

Specifications

Stroke: 1.0 gallons (3.8 liters)

Weight: Polypropylene - 165 lbs (75 kg)
PVDF - 271 lbs (123 kg)

Porting Size: 3" ANSI Flange or 80 mm DIN Flange

Capacity: 0- 280 gpm (1060 lpm)

Solids Handling: Up to 3/4" (19mm)

Air Distribution Valve: No-lube, no-stall design

Heads up to: 100 psi or 231 ft of water (7 bar or 70 meters)

Max Operating Pressure: 100 psi(7 bar)

S30 Non-Metallic 3" (80 mm) AODD – Standard Duty Non-Metallic Ball Valve Pump

The SANDPIPER S30 NON-METALLIC 3" (80 MM) AODD pump is unmatched in its class for bulk transfer applications. This diaphragm pumps' innovative design combines industry-leading flow rates with minimal air consumption, offering the most efficient and economical pumping solution for high-volume fluid transfer needs.

Features		Applications
Corrosion-Resistant Material Options: Available in polypropylene or PVDF, providing excellent chemical resistance for handling aggressive and abrasive fluids. Quick Serviceability: The ESADS+ air distribution system is engineered for easy access, allowing fast in-line service and repair for maximum uptime. Trusted Simplicity: SANDPIPER’s original ADS design is fully interchangeable, repairable, and inline-serviceable, reducing the need for costly inventory and minimizing compatibility issues common with other brands.		Chemical Processing: Suitable for handling corrosive and aggressive chemicals in bulk. Bulk Fluid Transfer: Ideal for high-volume transfer applications requiring fast, efficient handling. Industrial processes: Perfect for industries with continuous, heavy-duty fluid management needs.

Why Choose SANDPIPER AIR OPERATED DOUBLE DIAPHRAGM PUMP
Exceptional Flow and Efficiency: Achieves class-leading flow rates with optimized energy use, minimizing operational costs.	Patented ESADS+: SANDPIPER’s unique externally serviceable ADS allows maintenance without pumping removal, cutting service time from 55 to just 5 minutes.	Durable, Leak-free Construction: Built with robust, all-bolted stainless steel fasteners to ensure leak-free performance in demanding bulk transfer environments.
