S10 Non-Metallic 1" (25 mm) AODD – Standard Duty Non-Metallic Ball Valve Pump

S10 Non-Metallic 1" (25 mm) AODD – Standard Duty Non-Metallic Ball Valve Pump

Brand: Sandpiper

Category: Diaphragm Pumps (AODD Pump), Standard Duty Ball Valve Pump

Quantity: Out of Stock

Select variant(s): Model Number

Model Number:

We will send you a notification as soon as this product is available again.

AODD Pump for General and Chemical Industry

Official Distributor of Sandpiper AODD Pump

1" Plastic AODD Pump

1 inch air-operated double diaphragm pump

Ultra-compact AODD Ball Valve Pump

S15 Non-Metallic 1½" (40 mm) - Standard Duty Ball Valve AODD Pump

S07 Non-Metallic ¾" (20 mm) AODD – Standard Duty Non-Metallic Ball Valve Pump

Description

Specifications

Stroke: 0.026 gallons (0.98 liters)

Weight: Polypropylene - 19 lbs(9 kg)
PVDF - 23 lbs (10 kg)
Nylon - 20 lbs(9 kg)

Porting Size: 1" ANSI FLANGE

Capacity: No-lube, no-stall design

Solids Handling: Up to 0.15" (4 mm)

Heads up to: 100 psi or 231 ft of water (7 bar or 70 meters)

Max Operating Pressure: 100 psi (7 bar)

S10 NON-METALLIC 1" (25 MM) AODD - STANDARD DUTY NON-METALLIC BALL VALVE PUMP

The SANDPIPER S10 NON-METALLIC 1" (25 MM) has established itself as a trusted, class-leading double diaphragm pump, suitable for various markets and applications such as chemical processing or any other general industry. This metallic AODD pump provides remarkable lightweight portability and versatility, enabling it to handle both corrosive fluids and small suspended solids effectively. The durable, bolted construction of the S10 is superior to clamped-band construction pumps, ensuring exceptional performance. The Sandpiper 1" air-operated double diaphragm pump is designed to be driven by compressed air or nitrogen.

Features		Applications
Ultra-Compact Design: Efficient lightweight construction allows for easy transport and installation. Durable Construction: Engineered for reliability and longevity, ensuring consistent performance. Chemical Resistance: Designed to handle a wide range of chemicals, making it suitable for various applications.		Chemical processing: Ideal for dispensing chemicals in manufacturing and processing environments. Paint and coatings: Excellent for handling paints, adhesives, and coatings with minimal waste and efficient flow. Food and beverage: Suitable for transferring food-grade liquids, ensuring compliance with safety standards. OEM Applications

Why Choose SANDPIPER AODD Pump
Portability: The compact design allows for easy movement and setup in various environments.	Quick Maintenance: SANDPIPER’s original ADS is fully interchangeable, repairable and inline-serviceable, reducing downtime.
