S07 Non-Metallic ¾" (20 mm) AODD – Standard Duty Non-Metallic Ball Valve Pump

S07 Non-Metallic ¾" (20 mm) AODD – Standard Duty Non-Metallic Ball Valve Pump

Brand: Sandpiper

Category: Diaphragm Pumps (AODD Pump), Standard Duty Ball Valve Pump

Quantity: In Stock

non-metallic aodd pump

Official Distributor of Sandpiper AODD Pump

3/4" Plastic AODD Pump

AODD pump for chemical and painting industry

Bolted construction AODD Pump

S10 Non-Metallic 1" (25 mm) AODD – Standard Duty Non-Metallic Ball Valve Pump

S05 Non-Metallic ½" (15 mm) AODD – Standard Duty Non-Metallic Ball Valve Pump

Description

Specifications

Stroke: 0.026 gallons (0.098 liters)

Weight: Polypropylene - 17-21 lbs (8-9.5 kg)
PVDF 21 lbs (9.5 kg)
Nylon 18 lbs (9kg)

Porting Size: 3/4" NPT (Internal) or 3/4" NSP (Tapered)
1 1/2" (External) or 1/2" BSP (Tapered)

Capacity: 0 - 23 gpm (87 lpm)

Air Distribution Valve: No-lube, no-stall design

Heads up to: 100 psi or 231 ft of water (7 bar or 70 meters)

Max Operating Pressure: 100 psi (7 bar)

S07 NON-METALLIC 3/4" (20 MM) AODD - STANDARD DUTY NON-METALLIC BALL VALVE PUMP

The SANDPIPER S07 NON-METALLIC ¾" (20 MM) AODD pump has established itself as a trusted, class-leading positive displacement pump, perfect for many types of industries such as chemical or painting industry. The Sandpiper S07 series offers lightweight portability and the versatility to handle corrosive fluids and small suspended solids. Its trihedral valve options enhance product handling, ensuring gentle movement while preventing damage. The durable bolted construction of this type of bolted-construction double diaphragm pump is superior to clamped-band construction pumps, ensuring exceptional leak-free performance. This pump is designed to operate using compressed air nitrogen.

Our Sandpiper S05 AODD Pumps come in non-metallic materials such as PVDF, PTFE, Polypropylene, Conductive Polypropylene, Conductive PVDF, and Nylon with elastomer TPE (Thermal Plastic Elastomers) and PTFE options in diaphragms and check valves.

Features		Applications
Ultra-Compact Design: Efficient lightweight construction allows for easy transport and installation. Durable Construction: Engineered for reliability and longevity, ensuring consistent performance. Chemical Resistance: Designed to handle a wide range of chemicals, making it suitable for various applications.		Chemical processing: Ideal for dispensing chemicals in manufacturing and processing environments. Paint and coatings: Excellent for handling paints, adhesives, and coatings with minimal waste and efficient flow. Food and beverage: Suitable for transferring food-grade liquids, ensuring compliance with safety standards. OEM Applications

Why Choose SANDPIPER AODD Pump
Versatile Handling: Capable of managing corrosive fluids and small suspended solids with ease.	Quick Maintenance: SANDPIPER’s original ADS is fully interchangeable, repairable and inline-serviceable, reducing downtime.
