S05 Non-Metallic ½" (15 mm) AODD – Standard Duty Non-Metallic Ball Valve Pump

S05 Non-Metallic ½" (15 mm) AODD – Standard Duty Non-Metallic Ball Valve Pump

Brand: Sandpiper

Category: Diaphragm Pumps (AODD Pump), Standard Duty Ball Valve Pump

Quantity: Out of Stock

Select variant(s): Model Number

Model Number:

We will send you a notification as soon as this product is available again.

AODD Pump for Abrasive Fluid

Non-Metallic Diaphragm Pump for Small Suspended Solids

1/2" Ball Valve Pump

Bolted Plastic AODD Pump

S07 Non-Metallic ¾" (20 mm) AODD – Standard Duty Non-Metallic Ball Valve Pump

PB ¼" (6 mm) Non-Metallic AODD – Standard Duty Non-Metallic Ball Valve Pump

Description

Specifications

Stroke: 0.026 gallons (0.98 liters)

Weight: Polypropylene - 17-21 lbs(8-9.5 kg)
PVDF - 21 lbs(9.5 kg)

Porting Size: 1/2" NPT (Internal) or 1/2" BSP (Tapered)
1" NPT(External) or 1" BSP (Tapered)

Capacity: 0 - 14 gpm (52 lpm)

Air Distribution Valve: No-lube, no-stall desgin

Heads up to: 100 osi or 231 ft of water
(7 bar or 70 meters)

Max Operating Pressure: 100 psi (7 bar)

S05 NON-METALLIC 1/2" (15 MM) AODD - STANDARD DUTY NON-METALLIC BALL VALVE PUMP

The SANDPIPER S05 NON-METALLIC ½" (15 MM) is a class-leading air-operated double-diaphragm pump designed for a variety of industries and applications, renowned for its light-weights portability and versatility. Simple yet versatile, our Sandpiper plastic AODD pumps can be cleaned or repaired within 5 minutes, minimizing your production downtime. With its ability to handle corrosive fluids and small solids, this type of positive displacement pumps are widely applicable to different industries such as chemical or waste water treatment

Our Sandpiper S05 AODD Pumps come in non-metallic materials such as PVDF, PTFE, Polypropylene, Conductive Polypropylene, Conductive PVDF, and Nylon with elastomer TPE (Thermal Plastic Elastomers) and PTFE options in diaphragms and check valves.

Features		Applications
Lightweight Design: The ultra-compact structure allows for easy transport and installation. Durable Construction: The bolted design ensures exceptional leak-free performance, surpassing traditional clamp-band constructions Corrosion resistance: Suitable for handling corrosive fluids, making it ideal for demanding environments Performance Capabilities: effectively manages small suspended solids, broadening application use.		Chemical processing: Ideal for dispensing chemicals in manufacturing and processing environments. Paint and coatings: Excellent for handling paints, adhesives, and coatings with minimal waste and efficient flow. Food and beverage: Suitable for transferring food-grade liquids, ensuring compliance with safety standards. OEM Applications

Why Choose SANDPIPER S05 AIR OPERATED DOUBLE DIAPHRAGM
Simple design: SANDPIPER’s original ADS is fully interchangeable, repairable and inline-serviceable, minimizing maintenance complexities.	Quick Serviceability: With the ESADS+ feature, complete access to the ADS allows repairs or cleaning in just five minutes, compared to 55 minutes for competitors.	Operational Versatility: Designed to be driven by compressed air or nitrogen, offering flexible operation based on user needs.
