SH2-M Metallic 2" (50 mm) 2:1 High Pressure – Flap Valve Pump

SH2-M Metallic 2" (50 mm) 2:1 High Pressure – Flap Valve Pump

Brand: Sandpiper

Category: Positive Displacement Pumps

Quantity: In Stock

2 inch aodd pump

METALLIC AODD PUMP

50 mm

High Pressure Flap Valve Pump

F15C 1½" (40 mm) & F20C 2" (50 mm) Metallic AODD – SANITARY Ball Valve Pump

HP20 2" (50 mm) Metallic High-Pressure Ball Valve Pumps

Description

Specifications

Stroke: 0.3 gallons (1.1 liters)

Weight: Aluminum - 138 lbs (63 kg)
Cast Iron - 150 - 160 lbs (68-73 kg)

Porting Size: 2" NPT

Capacity: 0 - 120 gpm (454 lpm)

Solids Handling: Up to 1.8" (46 mm)

Air Distribution Valve: No-lube, no-stall design

Heads up to: 250 psi or 577 ft of water
(17 bar or 176 meters)

Max Operating Pressure: 125 psi (8.6 bar)

SH2-M Metallic 2" (50 mm) 2:1 High Pressure – Flap Valve Pump

The SANDPIPER SH2-M METALLIC 2" (50 MM) 2:1 is uniquely designed as the only high-pressure flap valve pump in the world, capable of achieving discharge pressures up to 250 psig (17.2 barg). This AOD pump combines high discharge pressure with superior solids handling, making it ideal for demanding applications such as filter press feeds and high-solids content fluid transfers.

Features		Applications
High-Pressure Performance: Delivers a 2:1 pressure ratio, achieving discharge pressures twitch the inlet pressure, up to 250 psig (17.2 barg) Durable and Reliable Construction: Metallic Seats and Heavy-Duty Flap valves: ensures a secure valve seal for performance under high-pressure conditions. Balanced diaphragm design: minimizes pressure differential, reducing wear and maintenance needs Efficient Maintenance ESADS+: Provides quick, external access to the air distribution system, enabling repairs or cleaning in five minutes without pump removal. Exceptional Solids Handling: Flap valve design handles solids up to 1.8” (45mm), maintaining efficient flow and preventing clogs in high-solids environments. Optimized Stroke Control: Independently regulated suction stroke control for smooth and adjustable performance. Material Options: Available in aluminum and cast iron with elastomer options to handle various fluid properties.		High-Pressure Solids handling: ideal for high-solids fluid application and sludge management Demanding, High-Pressure Applications: Suited for filter press feeds and applications needing higher discharge pressures. Heavy-Duty Industrial Use: Excellent for mining, wastewater, and industrial processes requiring durable, clog resistant performance.

Why Choose SANDPIPER HIGH PRESSURE FLAP VALVE PUMP
Unmatched Pressure and Solids Capacity: Ideal for applications with high pressure and heavy solids, such as dewatering, waste handling, and sludge transfer.	Minimized Downtime: ESADS+ system enables easy, on)site servicing, reducing downtime by up to 90%
Lower Total Cost of Ownership: Balanced diaphragm and durable flap valve construction reduce wear, extending the pump’s service life.	Superior Flow Control: Independently adjustable suction stroke for optimized performance, making it suitable for high-viscosity and high-hed applications.
