HP10 1" (25 mm) Metallic High-Pressure Ball Valve Pumps

HP10 1" (25 mm) Metallic High-Pressure Ball Valve Pumps

Brand: Sandpiper

Category: Positive Displacement Pumps

Quantity: In Stock

1 inch aodd pump

METALLIC AODD PUMP

25 mm

high pressure ball valve pump

HP series

HP20 2" (50 mm) Metallic High-Pressure Ball Valve Pumps

EH2-M Metallic 2" (50mm) AOD – High-Pressure Ball Valve Pump

Description

Specifications

Stroke: 0.13 gallons(0.48 liters)

Weight: Aluminum - 52.5 (25.5 kg)
Stainless Steel/Aluminum - 76.1 lbs (34.5kg)

Porting Size: 1" NPT / BPT

Capacity: 0- 33 gpm (125 lpm)

Solids Handling: Up to 1/8" (3 mm)

Air Distribution Valve: No-lube, no-stall design

Heads up to: 232 psi or 535 ft of water (16 kg/cm2 or 163 meters)

Max Operating Pressure: 116 psi (8 bar)

HP10 1" (25 mm) Metallic High-Pressure Ball Valve Pumps

The SANDPIPER HP10 1" (25 MM) METALLIC is designed to deliver nearly double the inlet pressure, making it an ideal solution for handling thick, viscous fluids and applications requiring high discharge pressures over long distances. Equipped with two additional air chambers and an extra air-side driver diaphragm, it maximizes pressure while maintaining excellent flow rates.

Features		Applications
High-pressure Performance: Delivers nearly 2:1 pressure ratio, handling pressures up to 232 psi (16 bar) with a maximum flow rate if 33 gpm (125 lpm) Self-Priming and End-Ported Design: Optimized for improved flow characteristics Robust Construction: Bolted assembly ensures greater integrity, durability, and ease of maintenance Deadhead Capability: Stalls against a closed head without causing damage On-Demand Restart: Automatically reinitiates when required Check Valve design: Weighted check valve balls ideal for high-viscosity and high-specific-gravity fluids ATEX Certification: Approved for safe use in hazardous environments		Industrial Fluid Handling: Ideal for transferring viscous fluids over extended distances High-Pressure Environments: Suitable for applications needing elevated pressure and reliable performance Viscous or High-Specific-Gravity Fluids: Designed to handle difficult-to-move materials with ease

Why Choose SANDPIPER HIGH PRESSURE BALL VALVE PUMPS
Safety in high-pressure operations: Deadhead capability protects the pump and restarts on demand, enhancing reliability and safety.	Improved Flow Efficiency: Self-priming, end-ported design enhances flow and fluid transfer efficiency
Ease of Maintenance: Simple construction with bolted assembly allows for quick and reliable servicing	Versatile material Options: Suitable for a wide range of fluids, including viscous and high-specific-gravity types
